Description
The DS-PDMCX-E-WB is a wireless external opening detector, ideal for outdoor applications, UV stable.
Model: DS-PDMCX-E-WB
Features
- Wireless External Magnetic Contact
- IP66 protective level, UV stable
- Fully remote configurable through App
- Multiple enrollment methods and easy installation design
- Frequency hopping against jamming for reliable transmission
Specifications
- Detection MethodOpening Contact
- Detection Gap76mm Max
- Feature
- Digital ProcessingSupport
- Tamper ProtectionFront;Rear
- Environment Temperature IndicatorSupport
- Signal Strength IndicatorSupport
- Interface
- Alarm InputNormally Closed;Normally Open;Impulse Count
- Power SwitchPower Up Enrolling
- LED IndicatorBlue (Alarm)
- Transmission
- Transmission TechnologyTri-X Wireless
- Transmission MethodTwo-Way RF Wireless
- Transmission Frequency433MHz
- Transmission SecurityAES-128 Encryption
- Transmission Range(Free Space)1Km
- Frequency HoppingSupport
- Enrolling MethodPower up;Remote ID;QR Code
- Electrical Characteristics
- Standard Battery Life5 years
- Power SupplyBattery Powered
- Battery TypeCR123A x 1
- Typical Voltage3V
- General
- Operation Temperature-20 °C to 60 °C (-4 °F to 140 °F)
- Storage Temperature-30 °C to 60 °C (-22 °F to 149 °F)
- Operation Humidity10% to 90%
-
Dimension(WxHxD)
Sensor: 40.5mm × 146mm × 40.9mm
Magnetic Stick: 30.5mm × 146mm × 40.9mm
- 247g
- Application Scenario Outdoor, IP66
Downloads
Hikvision Wireless External Magnet Detector, DS-PDMCX-E-WB
Hikvision Wireless Alarm Brochure
Warranty
Hikvision Alarm Systems products are covered by a 2 years Manufacturer Warranty from the date of purchase.
CTC Security offers a 1 year warranty on labour when the system is installed by us.
Customer to cover warranty postage for any replacement parts.
