Description
Risco BWare Quad PIR 15mtr G3 Detector Stay secure with an advanced G3 Detector. This reliable, long-range detector will help ensure your safety.
Model; RK500Q0G300A
Features
- 15m 90° Coverage
- 2 Dual Element PIR's
- Convex Fresnel Lens
- Anti-Mask Detection Active Infrared
- White Light Optical Filtering
- True Temperature Compensation
- Built-in Triple EOL resistors, jumper selectable
- Gold Plated Wall and Cover tampers
- True temperature compensation
- Output Contacts Alarm, Tamper & Fault/AM
- Installation height 2.1m - 3.3m
DESCRIPTION
BWare™, RISCO Group’s state-of-the-art wired and wireless detector series for professional installations, scores high points for its smart and modern design in addition to its advanced technology and reliability.
The BWare™ series offers a comprehensive array of wired, wireless and Bus detectors utilizing RISCO’s industry-leading detection technologies, such as Anti-Cloak™ and K-band microwave for improved catch performance, including a unique wireless DT detector with active IR anti mask.
The BWare™ series is ideal for a wide range of commercial and high security applications, with Grade 2 and Grade 3 versions. The BWare™ smart detector family provides you with the flexibility to utilize professional detectors in any installation - wired, wireless
FUNCTIONS
BWare™ smart detector line provides professional installers with the ultimate choice for high-security commercial and residential installations. The wide selection of models offer the flexibility to choose the best fit for all installation types, whether for a bank, jewellery shop, office, or any other commercial or residential site.
The BWare™ smart detector series also utilizes several advanced technologies unique to RISCO Group for superior performance:
Grade 3 for increased security
BWare™ Grade 3 detectors meet and exceed EN50131 Grade 3 standards and include additional features that increase reliability and false alarm immunity
Convex Lens for enhanced performance
BWare™’s convex lens is superior as its larger size and convex shape allow more infrared radiation to enter the detector, improving focus on the sensor and enhancing performance and sensitivity.
Built-in EOL Resistors for ease of installation
BWare™ relay detectors include built-in end-of-line resistors eliminating the need for installers to attach resistors in the detector, simplifying the installation and saving time.
Active IR Anti Mask
BWare™ Grade 3 and Wireless DT detectors include Active IR technology which checks for deviations in lens transparency and reflections close to the lens. Active IR is the most reliable anti-mask method as it continuously checks the physical capability of the detector to see through the lens, for indicating masking and for cancelling mask status.
SPECIFICATIONS
| EN50131 | Grade 3, Class II |
| Coverage | 15m (50’) 90° |
| Mounting Height | 2.1m - 3.3m |
| Detection Sensors | 2 Dual Element PIRs |
| Anti-Cloak™ Technology (ACT) | - |
| Lens type | Convex Fresnel Lens |
| Green Line™ Technology | - |
| Anti-Mask detection method | Active Infrared |
| Extra Zone Input for Bus models | ? |
| Built-in EOL resistors for Relay models | Triple EOL |
| Tampers | Gold plated wall & cover tampers |
| LED & Set inputs for relay models | ? |
| White Light Optical Filtering | Pigmented PIR covers |
| Temperature Compensation | Patented True Temperature compensation |
| Operating Voltage wired models: | 9 to 16VDC |
| Wired models Current Consumption at 12VDC | 14mA (typical) 34mA (max.) |
| Output Contacts on relay models: 100mA, 24V, N.C |
Alarm, Tamper & Fault/AM |
| Wireless models power | - |
| RF immunity: 10MHz to 3GHz | According to EN50130-4 |
| Dimensions (HxWxD) | 120x64x40mm |
