Description
Risco WL Beyond Outdoor Detector Dual Technology 433MHz
Model, RWX350D0400A
Features
- For Agility & Lightsys
- 433MHz
- Coverage: 12m, 90°
- Anti-Mask detection method: Active Infrared
- Pet Friendly: Animals up to 35cm head height
- Tamper: Wall, 3-axis Accelerometer
- Environment rating: IP 65
- Installation Height: Typical 2.2m
Unparalleled Catch Performance enabled with Dual Technology
Dual Technology (DT) combines two K-band microwave channels with two PIR sensors for better catch performance and pet immunity, minimizing false alarms.
Flexible Installation
Beyond is completely wireless and simple to install in any location that lacks wiring infrastructure. Setting the most effective and appropriate range according to specific installation requirements is allowed thanks to the flexible installation of both adjustable 180° Swivel Bracket, as well as the mounting height, which varies from 1.8m to 2.7m.
Unique Detection Technologies designed for the Outdoors
RISCO Group’s Sway Recognition™ Technology recognizes and dismisses objects that sway and move repeatedly, such as swaying bushes and trees, eliminating them as intrusion events. Digital Correlation™ Technology ensures that only targets causing similar and correlating signals in both PIR channels are seen as potential threats.
Direct Sunlight Immunity to eliminate false alarms
RISCO Group’s Direct Sunlight Immunity is based on a special algorithm that ignores sudden changes in the intensity of the sunlight, thus eliminating one of the major causes of false alarms in the outdoor environment.
Specifications
Coverage | 12m, 90° |
Installation Height | Typical 2.2m |
Microwave | K-band, 22 dual element sensors, 2 separate lenses channels |
PIR | 2 dual element sensors, 2 separate lenses |
Frequency | 433.92 MHz |
Anti-Mask detection method | Active Infrared |
Tamper | Wall, 3-axis Accelerometer |
Pet Friendly | Animals up to 35cm head height |
Operating voltage | 3xCR123 3V lithium batteries |
Battery life (Typical) | 3 Years, 6 Years with Solar Option |
RF Immunity | 10MHz to 3GHz. According to EN50130-4 |
Operating Temp | -25° C to 65° C |
Storage Temp | -25° C to 70° C |
Environmental Rating | IP 65 |
Dimensions (HxWxD) | 176X89X107mm |
Wireless Dual Technology | Yes |
Shock Based Tamper (Accelerometer) | Yes |
Direct Sunlight Immunity | Yes |
Advanced Outdoor Detection algorithms | Sway Recognition, Digital Correlation |
